SPECIALIZED RUBBER HOSES - OIL, LPG & CHEMICAL

MANUFACTURING STANDARD:
BS 3492 Type 1B/2B
BS 1435 Type S7/S10/S15
EN 1765 Type S7/S10/S15
IS 10733 Type 1B/2B
IS 10733 Type S7/S10/S15

LINING
Smooth bore, mandrel built, Nitrile lining to convey all grades of oil and petroleum products, including crude oils and other liquid petroleum products having a maximum aromatics content of 40% (For 100% aromatic content a Viton lining is available).

REINFORCEMENT
Fabric to reinforced lining, with multiple plies of synthetic cord fabric surrounding embedded high tensile steel wire helix.
Oil hoses are supplied electrically continuous unless specifically requested to be electrically discontinuous.

COVER
Smooth, Polychloroprene (Neoprene) rubber compounded to resist abrasion, weathering and oil.

WORKING PRESSURE – VACUUM
A 600 7 bar -0.85 BAR
A 501 10 BAR -0.85 BAR
A 602 15 BAR -0.85 BAR

SAFETY FACTOR
2 : 1

SIZES :
2" (50mm nominal) – 12" (300mm nominal). Lengths up to 19.5mtrs.

TEMPERATURE RANGE:
- 20°C TO + 82°C.

Hose specification:
BS EN 1762:2003 Type SD

Lining:
NBR rubber compound, smooth bore, resistant to n-pentane and aromatic contents up to 50%.

Reinforcement:
Multiple plies of Polyester Tyre cords plus stainless steel helical wire embedded in synthetic rubber

Cover
Synthetic black chloroprene rubber compound, weather, oil, abrasion and seawater resistant.

Working Pressure:
25 Bar

Safety Factor:
4 : 1

Nominal bore
3", 4", 6", 10", 12"

Temperature Range
-30°C to + 70°C

HOSE APPLICATION:
As per EN 13482:2001

APPLICATION:
A robust hose specially constructed to transfer bitumen, asphalt and tar at upto 180 Deg C.

LINING
Black, smooth Complex heat resistant synthetic rubber and fabric carcass.

REINFORCEMENT
Multiple layers of heat resistant synthetic cord plus a single steel helix.

COVER
Smooth wrap finish cover giving excellent resistance to oil, weathering and abrasion.

WORKING PRESSURE – VACUUM
15 bar – Full vacuum.

SIZE RANGE :
2" – 12"

APPLICATION:
Suction and delivery of abrasive material such as dry cement, grains, flour, powders and sand.

LINING
Black Smooth, antistatic rubber to withstand passage of highly abrasive material.

REINFORCEMENT
Multiple layers of synthetic cord plus a single steel helix, giving a minimum bend radius of 6x bore size.

COVER
Corrugated for greater flexibility. Tough weather and abrasion resistant.

WORKING PRESSURE – VACUUM
10 bar – 0.85 bar.

SAFETY FACTOR
3.5 : 1

SIZE RANGE :
2" (51 MM) – 36" (915MM)
